Bluetooth capacity indicator 0-120V 100A

Bluetooth RS485 10V-80V capacity indicator for all types of batteries.

This capacity indicator (coulombmeter) is designed to measure various parameters such as voltage, current, power, charge and discharge capacity, watt-hours and time.

At the same time, it can set parameters to obtain various protections : protection against overvoltage and undervoltage, protection against overcurrent and overtemperature.

The meter can automatically identify the direction of the current, monitor battery capacity in real time and display measured data via Bluetooth. It can also control meter and firmware upgrades via the mobile app. It can communicate via an RS485 link.

The maximum Bluetooth communication distance is 10 metres.

TECHNICAL SPECIFICATIONS

100A shunt current measurement

Voltage range (external power supply) : 0-120V
Measuring range (self-powered) : 10-80V
Power range : 0-72KW
Resolution voltage : 0.01V
Current measurement : 0-100A
Current resolution : 0.01A
Operating temperature : -20°C to 120°C
Weight : 326g

STANDARDS

Certifications : RoHS I CE

Warranty - 2 years
